*Frame
Size: XS , S
Alpha Silver Aluminum, curved top tube, internal routing, chainstay disc brake mount, rack and kickstand mount, 135x5mm QR
Size: M , ML , L , XL , XXL
Alpha Silver Aluminum, internal routing, chainstay disc brake mount, rack and kickstand mount, 135x5mm QR
*Fork
Size: XS
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42mm offset for 27.5” wheel, 100mm QR, 80mm travel
Size: S
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42mm offset for 27.5” wheel, 100mm QR, 100mm travel
Size: M , ML , L , XL , XXL
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 46mm offset for 29” wheel, 100mm QR, 100mm travel
Wheels

Hub front
Formula DC-20, alloy, 6-bolt, 5x100mm QR
Hub rear
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR
Skewer rear
152x5mm QR
Rim
Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve
Spokes
14g stainless steel, black
*Tire
Size: XS , S
Bontrager XR2 Comp, wire bead, 30 tpi, 27.5×2.20”
Size: M , ML , L , XL , XXL
Bontrager XR2 Comp, wire bead, 30 tpi, 29×2.20”
Max tire size
Frame: 29×2.20″ (XS & S: 27.5×2.40″), Fork: See manufacturer
Drivetrain

Shifter
Shimano Deore M4100, 10 speed
Rear derailleur
Shimano Deore M5120, long cage
*Crank
Size: XS , S , M , ML
Prowheel C10Y-NW, 30T steel narrow-wide ring, 170mm length
Size: L , XL , XXL
Prowheel C10Y-NW, 30T steel narrow-wide ring, 175mm length
Bottom bracket
Sealed cartridge, 73mm
Cassette
Shimano Deore M4100, 11-46, 10 speed
Chain
KMC X10, 10 speed
Pedal
VP-536 nylon platform
Max chainring size
1x: See FAQ, 2x: 36T, 3x: 42T
Components

Saddle
Bontrager Arvada, steel rails, 138mm width
*Seatpost
Size: XS , S , M
Bontrager alloy, 31.6mm, 12mm offset, 330mm length
Size: ML , L , XL , XXL
Bontrager alloy, 31.6mm, 12mm offset, 400mm length
*Handlebar
Size: XS
Bontrager alloy, 31.8mm, 5mm rise, 690mm width
Size: S , M , ML , L , XL , XXL
Bontrager alloy, 31.8mm, 5mm rise, 720mm width
Grips
Bontrager XR Endurance Comp, lock-on
*Stem
Size: XS
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length
Size: S
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 60mm length
Size: M
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 70mm length
Size: ML , L
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 80mm length
Size: XL , XXL
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 90mm length
Headset
Semi-integrated, 1-1/8”
Brake
Tektro HD-M275 hydraulic disc, 180mm rotor
Brake Set
Tektro HD-M275 hydraulic disc, 160mm rotor
Weight

Weight
M – 14.11 kg / 31.11 lbs
