FRAME
C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing

Fully Integrated Battery

Advanced Internal Cable Routing

Modular Battery System

Adjustable headset angle

Agile Trail Geometry

High Performance Carbon

X-Connect
SIZE

SUSPENSION
SUSPENSION FORK
Fox 36 Float AWL HD Sport RAIL 2.0 R, Tapered, 15x110mm, E-Bike Optimized, 150mm
SHOCK
Fox Float Rhythm R, 230x60mm (27.5: 210x55mm), Adjustable LSR
SHOCK HARDWARE
Front: 30x8mm, Rear: DU-Bushing 12.7mm

E-BIKE SYSTEM
DRIVE UNIT

Bosch Drive Unit Performance Line CX max. 100Nm (BDU38)

REMOTE

Bosch System Control, incl. Mini Remote

BATTERY

Bosch PowerTube 800

DISPLAY

Bosch Purion 400

CHARGER

Bosch 2A

DRIVETRAIN & BRAKES
BRAKE SYSTEM
Shimano BR-MT420, Hydr. Disc Brake (203/203)
REAR DERAILLEUR
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
SHIFTERS
Shimano Deore SL-M6100-IR, Direct Attach, Rapidfire-Plus
CRANKSET
ACID MTB Hybrid Pro, 27.5: 36T // 29: 34T
CASSETTE
Shimano Deore CS-M6100, 10-51T
CHAIN
KMC e12
CHAIN GUIDE
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate

COCKPIT
HEADSET
ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface
STEM
CUBE Performance Stem E-MTB 35, FPI-Link
HANDLEBAR
CUBE Rise Trail Bar 35
GRIPS
ACID Disrupt

WHEELS
WHEELSET
ACID SLX 30, 32/32 Spokes, 15x110mm/12x148mm, Tubeless Ready
TYRES
Schwalbe Nobby Nic, Performance, 2.6

FINISHING KIT
SADDLE
ACID Venec EMTB Trail 140
SEAT POST
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
PEDALS
ACID PP MTB
