Alloy S-XL=29″, 6061 Alloy custom butted tubing
Side extraction battery
UDH Interface, 12x148mm with 52mm Chainline
Travel120mm
ForkSR Suntour XCM34 LO Coil, Tapered, 15×110 TA, Lock Out, 120mm Travel
Drive UnitBosch Performance Line CX (BDU384Y)
EU: 25kmh
BatteryPowerTube 600Wh
DisplayBosch System Controller
Intuvia 100
Mini remote
Charger2A Charger
Rear DerailleurShimano Deore RD M6100SGS 12 Speed
ShiftersShimano Deore SL-M6100RA
CranksetFSA CK-220 165mm
ChainguideSyncros
ChainringFSA 36T
ChainKMC E12S
CassetteShimano CS-M6100-12 10-51T 12 Speed
BrakesShimano BR-MT420 Disc Brakes
RotorFront: SM-RT30 CL 180mm, Rear: SM-RT30 CL 180mm
HandlebarSyncros 3.0 720mm, 31.8mm, Backsweep 9°, 12mm rise
Syncros Lock On Grip
H’stemSyncros with front Light mount and Intuvia 100 mount
SeatpostSyncros M3.0, 31.6
SeatSyncros Capilano
HeadsetAcros, 1.5″- 1.5″
semi integ. OD 50/61mm, ID 44/55mm
Front HubShimano HB-TC50015BB CL, 15x110mm
Rear HubShimano FH-TC500HMSBB CL, Boost 12x148mm
SpokesBlack Spokes
RimsSyncros X18 Disc
Front TireSchwalbe Advancer 60-622 Wired
Rear TireSchwalbe Advancer 60-622 Wired
LightsFront Lezyne Hecto E65
Rear Super Bright Lezyne Light
RackRacktime Micro Rack SnapIt 2.0 27KG
PedalsVP VPE-506
Approx weight in KG28.3
Approx weight in LBS62.39
Max. System Weight160kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
